auto feeding co2 laser cutting bed machine

large size 1630 150w nylon spandex denim jeans rexine cnc auto feeding co2 laser cutting bed machine


  • Item NO.:

    FLG-3016 5016 1325
  • Order(MOQ):

    1
  • Payment:

    T/T, L/C,DP,DA
  • Product Origin:

    Quanzhou,China
  • Shipping Port:

    Xiamen,China
  • Lead Time:

    10-15days

large size 1630 150w nylon spandex denim jeans rexine cnc auto feeding co2 laser cutting bed machine


denim jeans laser cutting bed

silk large laser cutting machine bed

fabric laser cutting bed

textile laser cutting bed


Features:

1.The steel frame has strong stability and high accuracy meeting the requirement of high speed cutting.

2.The mixed light path ensures the high efficiency for solar energy utilization and high security.

3.The special motion control software system ensures there is no overshooting and hysteresis when the laser head moves and

 conducts flexible machining.

4.It can achieve instant cutting working with garment CAD software, process automatically continuously and repeatedly the pattern

 which is over the cutting area after type setting, realizing automatic continuous production.

5.It has unique advantage for cutting the special cloth with the characteristic of auto winding, no rough selvedge, high accuracy

 and fast speed.

6.It is equipped with auto feeding system achieving the multilayer continuous cutting.

7.The models can be customized.



Advantage:

1. High precision, High stability, Fast speed
2. Low consumption
3.Strong and durable frame, Long life
4.Imported guide rail and transmission belt
5.Imported reflector and focus lens
6.Stepping motor and driving system
7.Advanced copyrighted software
8.Excellent cooling system
9. LED realtime display
10.DSP intelligent main board



Applicable Industries:

It is suitable for the industries, such as garment,shoe,bag jeans and suitcase,computerized embroidery and clipping,model,toy,electronics,furniture,advertising decoration,art ware, etc.



Applicable Materials:

Non-metallic material, such as leather,cloth,organic glass,acrylic,

rubber,plastic, wood ware,bamboo ware,ceramic , etc.



Technical Parameters of gown medical laser cutting bed machine


Processing Area(mm)

1300*2500 1600*3000 1600*5000mm

Engraving Speed

0-64000 mm/min

Cutting Speed

0-36000 mm/min

Laser Capacity

100w 130w 150w 180wCO2 glass tube

Resolution Rate

0.0064mm

Min Shaping Character

Chinese character:2*2mm, Letter:1*1mm

Power supply

AC220±10%,50HZ

Positional Accuracy

<0.01mm

Repeated Positional Accuracy

0.01mm

Total Power

 ≤3000w

Working temperature

0-45

Working Humidity

5%-95%(No Condensation)

Type of belt drive

X-direction outward sliding or inward sliding guide rail+3m synchronous belt; Y-direction outward sliding or inward sliding guide rail+3m synchronous belt

Air exhaust

Big capacity lower air exhaust

Graphic Format Supported

PLT,AI,DXF,DST,BMP,GIF,JPEG,PCX,TGATIFF,CDR,DMW, etc.

Optical system

Φ25mm Molybdenum reflector;  Φ25mm Silicon reflector; Φ20mm, focal length50.8 focusing mirror

Dimension(mm)

9060

1480*1080*1100



Sample show:


laser cutting bed price



Our Payment:

1) Usually we accept T/T, Irrevocable L/C at sight.

2) 30% deposit, the 70% balance should be paid clear before delivery.

3) The delivery day is 7-10 working days.

4) The MOQ is 1set.



How to choose our machine:

The following information is important for us to recommend you the suitable models of laser cutting/engraving machine:

1) What materials and size will you cut?

2) What laser capacity and working area size you need?

3) What industries are you in, shoe, clothes, handicraft or advertisement?

4) Your destination port, it is for checking shipping price.

5) Other relative information, please let me know.



Packaging & Shipping of auto feed laser cutting machine bed

1) Standard seaworthy plywood case, without fumigation, can be exported directly.

2) Forklift-lift loading, much safer for machine.

3) We will arrange telex release for you or send original BL to you for customs clearance.
