Auto feeding webbing laser cut machine with camera

Auto feeding webbing laser cut machine wiht camera is with auto feeding webbing cutting platform, suitable for cutting long roll webbing, such as printed webbing、strap、 seat belt、nylon webbing、woven label、polyester webbing、leather belt、Velcro, tapes、pvc webbing,etc.

  • Item NO.:

    FLG-9060 1080 1680
  • Order(MOQ):

    1
  • Payment:

    TT, LC at sight, DP, DA
  • Product Origin:

    Quanzhou, China
  • Shipping Port:

    Ximen, China
  • Lead Time:

    10-15 days

0086-18815980123  0086-13599259031  Boming laser


Auto feeding webbing laser cut machine with camera is for cutting whole roll webbing trademark woven label. The camera is optional. If  the webbing has printed pattern, can choose the camera model. There are two kinds of feeding table, one is simple with roller to feed the webbing, another is feeding chain, suitable for thick webbings.


Machine pictures: of laser cut webbing


Webbing laser cutter machine

webbing laser cutter

webbing laser cutting machine

auto feed webbing laser cutting machine




Features:of auto feeding webbing laser cut machine wiht camera

1、It adopts the top grade advanced CO2 laser tube, with the quality of delivering 24 hours consistent laser power output and it also has high ability of anti-interference.

2、Adopting the three-dimensional reflection system and six-balanced out ward or in ward  sliding guiderail makes the laser beam moves consistently and ensures the high speed and precision of cutting and engraving.

3、Fast curve cutting function: any curves can be cut fast and continuously. The movement of laser head draws a perfect arc just like the top grade racing cars run.

4、It is integrated with LCD and DSP intelligent motherboard; offline work and USB data transmitting are available, no extra computer needed.

5、The customized maehines with different size are available.



Advantage: of laser cut webbing

1. High precision, High stability, Fast speed
2. Low consumption
3.Strong and durable frame, Long life
4.Imported guide rail and transmission belt
5.Imported reflector and focus lens
6.Stepping motor and driving system
7.Advanced copyrighted software
8.Excellent cooling system
9. LED realtime display
10.DSP intelligent main board



Machine Details:





Applicable Industries:of cnc laser cutting machine

Outdoor products, pet products, military security, luggage, clothing, shoes and hats, gifts and other industries.




Applicable Materials: of laser cutting machine for webbing

Polyester webbing, nylon webbing, polyamide, blended fabrics, leather belt, seat belt, woven label,strap and other knitting materials.




Technical Parameters:of automatic ribbon laser cutting machine

Laser Capacity

60W 80W 100W 130W 150W 300W 450W 600W CO2 glass tube

Processing Area(mm)

900*600 1000*800 1200*800 1300*900 1400*800 1600*800 mm

Positional Accuracy

±0.05mm

Working table

Special webbing cutting platform

Cutting Speed

0-36m/min

Max Traverse Speed

0-64m/min

Type of belt drive

X-direction outward sliding or inward sliding guide rail+3m synchronous belt; Y- direction outward sliding or inward sliding guide rail+3m synchronous belt

Air exhaust

Big capacity lower air exhaust

Graphic Format Supported

CDR,BMP,PLT,PCX,AI,DXF,DST,GIF, etc.

Optical system

Φ25mm Molybdenum reflector;  Φ25mm Silicon reflector;  Φ20mm, focal length50.8 focusing mirror




Sample show:




Our advantages:




Our Payment: of ccd camera laser cutting machine

1) Usually we accept T/T, Irrevocable L/C at sight.

2) 30% deposit, the 70% balance should be paid clear before delivery.

3) The delivery day is 7-10 working days.

4) The MOQ is 1set.




Why choose us:

1. 13 years experience on laser cutting and engraving machine.


2. Use good brand parts, excellent machine quality.


3. Free consulting, lifetime technical support.


4. Various optional types, customized acceptable.


5. Machines sold to Southeast Asia, South Asia, South America......


Purchase process:



Packaging & Shipping:

1) Standard seaworthy plywood case, without fumigation, can be exported directly.

2) Forklift-lift loading, much safer for machine.

3) We will arrange telex release for you or send original BL to you for customs clearance.




Our contact:
