2000W Raycus fiber laser welder machine

2000W Raycus fiber laser welder machine enables dramatically faster welding, is easier to learn and operate, and provides higher-quality, consistent results across a wider range of materials and thicknesses without distortion, undercut or burn-through.

The heat affected zone is dramatically minimized, as is the need for traditional post-processing grinding or polishing for increased productivity, less scrap and lower cost-per-part.


  • Item NO.:

    FLG-H1000W/1500W
  • Order(MOQ):

    1
  • Payment:

    TT, LC at sight, DP, DA
  • Product Origin:

    Quanzhou, China
  • Shipping Port:

    Ximen, China
  • Lead Time:

    10-15 days

0086-18815980123  0086-13599259031  Boming laser


2000W Raycus fiber laser welder machine adopts the latest generation of fiber laser machine, which has the advantages of simple operation, beautiful weld seam, fast welding speed and no consumables. It can be welded on metal materials such as thin stainless steel plate, iron plate and galvanized plate. Perfectly replace traditional argon arc welding, spot welding and other processes.



Machine pictures: of 1000 watt laser welder


1000w fiber laser welder

cheap laser welder

fiber laser welder price

handheld laser welding system



Features:of 1500w handheld laser welding machine

1、High Speed: Up to 4X Faster than traditional methods - increased productivity for lower costs-per-part;

2、High Quality: Consistent welding of thick, thin and reflective metals without distortion, undercut or

burn-through - minimal heat affected zone;

3、Easy to Use: Simple set up, easy to learn and operate for consistent high-quality welds;

4、Enhanced Material Capability: Metals with dissimilar thicknesses, ultra-thin parts, copper welding, materials with low and high electrical conductivity;

5、Wobble welding: Up to 5 mm of additional weld width - increases capability and creates highly aesthetic seams;

6、Operator safety: Multi-level sensors and interlock safety features.




Advantage: of aluminum laser welding machine

the  Laser welding is to irradiate a high energy density laser beam on two parts of the material, melt the material and then cooling and solidification into one. Compared with traditional welding technology, the Auto wire feeding hand held laser welding has the following advantages:


1、The weld seam is smoothe and beautiful, it doesnot need to be polished or the  workboard of the polish is very small;

2、Through control the laser energy, the welding will not defrom or very few deformation;

3、Handheld  laser welding machine is easy to handle and needn't to  require the  professional welders;

4、The wobble welding machine can handle the hard welding material easily, such as aluminum, brass;

5、Long life span up to 100,000 hours and low comsumption;

6The Auto wire feeding handheld welding machine can weld parts with wider gap;

7With a 8-15m fiber line, It can weld long-distance and large- area parts;

8Various welding processes, such as spot welding, seam welding and overlap welding;

9The welding efficiency is around 5 times of TIG welding;

10It is welding used in electronics, sheet metal, air condiction industry etc.





Applicable Industries:of fiber laser welder

Laser welding technology and laser welding machine are widely used in sheet metal processing, tool processing, rail transit, automobiles, electrical manufacturing, elevator manufacturing, decorative advertising , construction machinery, agricultural and forestry machinery, petroleum machinery, food machinery, household appliances, kitchen cabinets, kitchenware and bathroom,  shelves, ovens, stainless steel door and window guardrails, distribution boxes, stainless steel homes,Laser processing services, etc. and other industries,



Applicable Materials: of hand laser welding machine price

Aluminum,Stainless Steel, Carbon Steel,Copper,Silver, Titanium, Tin, etc.




Technical Parameters:of laser welder for sale


Technical Parameters


Laser

Max, Reci, Raycus, etc.

Laser Capacity

1000w 1500W 2000W

Laser wave length

1064nm

Fiber core diameter

50um

Cable length

8m

Laser working mode

Continuous / Modulation

Welding speed

0-120mm/s

Refrigeration unit

Intelligent dual temperature chiller

Working environment
temperature range

15-35

Humidity range of working environment

70% non-condensing

Welding material thickness

0≤4.5mm

Welding gap requirements

0.5mm

Operating environment

Clean, without dust or less dust

Total power

≤6500W

Power supply

AC220V±10%,50HZ

Cooling way

Water cooling

Laser pulse Frequency

1-5000Hz/ 50kHz

Spot size(mm)

0-4mm



Sample show:




Why choose us:

why choose us(boming).jpg



Fair show:


Boming Six Advantages:





Packaging & Shipping:

1) Standard seaworthy plywood case, without fumigation, can be exported directly.

2) Forklift-lift loading, much safer for machine.

3) We will arrange telex release for you or send original BL to you for customs clearance.
