stainless steel fiber laser marking machine

IPG Field Lens bottle metal seal carbon steel rule die 50w 30 watt mopa fiber laser marking machine

  • Item NO.:

    FLG-G20W 30W 50W
  • Order(MOQ):

    1
  • Payment:

    T/T, L/C,DP,DA
  • Product Origin:

    Quanzhou,China
  • Shipping Port:

    Xiamen,China
  • Lead Time:

    10 days

IPG Field Lens bottle metal seal carbon steel rule die 50w 30 watt stainless steel fiber laser marking machine

metal fiber laser marking machine

carbon steel fiber laser markimg machine

64x64

rings laser marker

Features:

1、Fast speed, equipped with high speed galvanometer
2、Small volume, light weight
3、No consumables, low power consumption, less than 500w.
4、Air cooling completely, without chiller, reducing energy consumption.
5、Not affected by bad environment and temperature change. It can work by using accumulator or car cigarette lighter.
6、Reducing the product depreciation cost greatly meets the customers' requirement of large quantity and stable production.
7、Rotating head, mobile platform, full automation system (optional).
8、It can be equipped with customized conveyor.



Advantage:

1, labor-saving, laser marking is permanent, unlike inkjet printer, inkjet printer solvent is therefore easy to apply.

2, green environmental protection, no pollution sources, refuse these pollution sources at the source.In today's environment especially tense process fiber laser marking machine will certainly become the mainstream.

3, easy to use, very small, accept the built-in air cooling mode, different semiconductor laser marking machine equipped with water cooling machine cooling, ice rock laser Co., Ltd., the company developed a variety of portable fiber laser marking machine, easy to transport and place.

4. The higher the power, the better the quality of the beam, the higher the photoelectric conversion rate, the clear logo, to ensure that the pattern is normal for a long time, the light path is closed, the light path is very short, and the waste can be eliminated.

5, the middle power is very low, compared with other laser marking machine, Q head, Q switch, Q power supply and other parts are less, and the built-in air cooling acceptance, so it can probably run out of power consumption.

6, long service life, very durable, can be used for up to 100,000 hours, compared to CO2 laser marking machine 30,000 hours and semiconductor laser marking machine 10,000 hours, the length of its life black and white often prevail, very appropriate for a long time to work.



Technical Parameters of metal fiber laser marking machine


Technical Parameters


Laser

From China

Laser Capacity

20w 30W 50W 100W

Laser wave length

1064nm

Optical quality

M2<1.5

Laser repetition frequency

≤100KHZ

Standard marking area(mm)

110*110

Optional marking area(mm)

110*110/150*150/300*300

Marking depth

≤1.2mm

Engraving speed

≤12000mm/s

Marking Speed

600-1000 character/min

Min line width

0.01mm

Min character

0.05mm

Repeated accuracy

±0.001

Operating environment

Clean, without dust or less dust

Total power

≤500W

Power supply

AC220±10%,50HZ,10A

Cooling way

Air cooling

Working temperature

0~45℃

Working humidity

5~95%



Sample pictures:

keyboard laser marking machine



Why choose us:

1. 13 years experience on laser cutting and engraving machine.

2. Use good brand parts, excellent machine quality.

3. Free consulting, lifetime technical support.

4. Various optional types, customized acceptable.

5. Machines sold to Southeast Asia, South Asia, South America......



Packaging & Shipping:of animal tag laser marking machine

1) Standard seaworthy plywood case, without fumigation, can be exported directly.

2) Forklift-lift loading, much safer for machine.

3) We will arrange telex release for you or send original BL to you for customs clearance.

4) As for the wholesalers/distributors, we could send the cargo by air, by sea or by railways via reliable forwarder.
